7" ELEMENTS
945
COOPER LIGHTING
IRIS
®
E7THWW Half Open Wall Wash
Add Cone Color and Flange style
Module/Lamp: P7 with M42T Module: 26/32/42W Triple Compact Fluorescent
PN7 with M42T Module: 26/32/42W Triple Compact Fluorescent
P7 with M32TLUTRON Module: 32W Triple Compact Fluorescent
PN7 with M32TLUTRON Module: 32W Triple Compact Fluorescent
P7 with M42T277 Module: 26/32/42W Triple Compact Fluorescent
Emergency version is available for these units.
Dimensions: OD: 8 1/4" (210mm) Aperture: 6 3/4" (172mm)
E7A21WW Single Open Wall Wash
Add Cone Color and Flange style
Module/Lamp: P7 with M120 Module: 150W A21, 100W TB15, 90W BT19, 100W MB19
PN7 with M120 Module: 150W A21, 100W TB15, 90W BT19, 100W MB19
Dimensions: OD: 8 1/4" (210mm) Aperture: 6 3/4" (172mm)
E7A21DWW Double Open Wall Wash
Add Cone Color and Flange style
Module/Lamp: P7 with M120 Module: 150W A21, 100W TB15, 90W BT19, 100W MB19
PN7 with M120 Module: 150W A21, 100W TB15, 90W BT19, 100W MB19
Dimensions: OD: 8 1/4" (210mm) Aperture: 6 3/4" (172mm)
E7A21CWW Corner Open Wall Wash
Add Cone Color and Flange style
Module/Lamp: P7 with M120 Module: 150W A21, 100W TB15, 90W BT19, 100W MB19
PN7 with M120 Module: 150W A21, 100W TB15, 90W BT19, 100W MB19
Dimensions: OD: 8 1/4" (210mm) Aperture: 6 3/4" (172mm)
E7A21HWW Half Open Wall Wash
Add Cone Color and Flange style
Module/Lamp: P7 with M120 Module: 150W A21, 100W BT15, 90W TB19, 100W MB19
PN7 with M120 Module: 150W A21, 100W BT15, 90W TB19, 100W MB19
Dimensions: OD: 8 1/4" (210mm) Aperture: 6 3/4" (172mm)
E7LWW Lensed Wall Wash
Add Cone Color and Flange style)
Module/Lamp: P7 with M120 Module: 90W PAR38, 60W PAR38HIR
PN7 with M120 Module: 150W PAR38, 100W PAR38HIR
Dimensions: OD: 8 1/4" (210mm) Aperture: 6 3/4" (172mm)
E7TCWW Corner Open Wall Wash
Add Color and Flange style
Module/Lamp: P7 with M42T Module: 26/32/42W Triple Compact Fluorescent
PN7 with M42T Module: 26/32/42W Triple Compact Fluorescent
P7 with M32TLUTRON Module: 32W Triple Compact Fluorescent
PN7 with M32TLUTRON Module: 32W Triple Compact Fluorescent
P7 with M42T277 Module: 26/32/42W Triple Compact Fluorescent
Emergency version is available for these units.
Dimensions: OD: 8 1/4" (210mm) Aperture: 6 3/4" (172mm)
7" WALL WASH ELEMENTS
